Security Stiffer Metal Door Plate CNC / Manual Spot Welding Machine , Galvanized Steel Welder

GUANGDONG HWASHI TECHNOLOGY INC.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Security Stiffer Metal Door Plate CNC / Manual Spot Welding Machine , Galvanized Steel Welder from wholesalers

    Buy cheap Security Stiffer Metal Door Plate CNC / Manual Spot Welding Machine , Galvanized Steel Welder from wholesalers
    • Buy cheap Security Stiffer Metal Door Plate CNC / Manual Spot Welding Machine , Galvanized Steel Welder from wholesalers
    • Buy cheap Security Stiffer Metal Door Plate CNC / Manual Spot Welding Machine , Galvanized Steel Welder from wholesalers

    Security Stiffer Metal Door Plate CNC / Manual Spot Welding Machine , Galvanized Steel Welder

    Ask Lasest Price
    Brand Name : HWASHI
    Model Number : WL-SQ-100k
    Certification : CE/CCC/ISO
    Price : negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per month
    Delivery Time : 7-30 working days after received your payment
    • Product Details
    • Company Profile

    Security Stiffer Metal Door Plate CNC / Manual Spot Welding Machine , Galvanized Steel Welder

    Security Stiffer Metal Door Plate CNC / Manual Spot Welding Machine , Galvanized Steel Welder


    DESCRIPTION


    1. Brainpower touch-screen microcomputer controller, completely digital control, automatic detection and compensation, loose welding and false welding are well prevented.


    2. Panasonic touch-screen hunan-computer interface, Panasonic programer is adopted as the control hub, in charging of reading and dealing with control signal to guarantee that the machine operation is in order and effective.


    3. Groups of welding electrodes can be moved from left to right, all kinds of products are suitable to be welded. Welding electrodes can work in flexible order. No metal sheet deformation.


    4. Pneumatic mechanism, the pressure of every electrode can be adjusted, stable force is achieved. The upper electrodes have an adjustable working distance forwards and afterwards, the lower electrode mould installation is simple and flexible to be adjusted from left to right.


    5. Encoding servo motor feeding rack mechanism, equipped with high precise slide guide and automatic detection device. Has the advantages of quick reac


    SPECIFICATION

    S.N.

    Items

    Parameters

    1

    Input voltage

    380V,3 phase

    2

    Input current

    395A

    3

    Output voltage

    DC12V

    4

    Max.short-circuit current

    40000A

    5

    Welding Models

    16 sets

    6

    Welding Position

    5000 points

    7

    Different welding current

    4 sets

    8

    Effective welding width

    1000mm (customized)

    9

    Effective welding length

    1200mm (customized)

    10

    Rack mobile speed

    600mm/sec

    11

    Rack mobile power

    Servo motor

    12

    Cross wire feeding system

    1 set


    APPLICATION

    This machine is widely used to weld metal sheet in electronic appliances, automobile and other area..


    COMPETITIVE ADVANTAGE

    1. HWASHI is the leading brand in resistance welding industry in China for 20 years; Factory direct sale, competitive price.

    2. Customized Service: We can help to design and develop the welding machine according to your requirement. We are flexible and capable Supplier.

    3. Genuine Product with Excellent Quality: 12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy 8-10 years service life. 100% guarantee test before delivery.

    4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here try our best to help you.

    5. Quick Delivery: Our company provides just-in-time delivery.

    6. Prompt Response to Customers: Your satisfaction is the goal we pursue.
