    Automatic Argon Arc Straight Seam TIG Welder for All Kinds of Mental Pipe , Circumferential Seam Welding Equipement

    Ask Lasest Price
    Brand Name : HWASHI
    Model Number : WL-YZ-1500
    Certification : CE/CCC/ISO
    Price : negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per month
    Delivery Time : 7-30 working days after received your payment
    • Product Details
    • Company Profile

    Automatic Argon Arc Straight Seam TIG Welder for All Kinds of Mental Pipe , Circumferential Seam Welding Equipement

    Automatic Argon Arc Straight Seam TIG Welder for All Kinds of Mental Pipe , Circumferential Seam Welding Equipement


    COMPETITIVE ADVANTAGE


    1. HWASHI is the leading brand in resistance welding industry in China for 20 years; Factory direct sale, competitive price.

    2. Customized Service: We can help to design and develop the welding machine according to your requirement. We are flexible and capable Supplier.

    3. Genuine Product with Excellent Quality: 12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy 8-10 years service life. 100% guarantee test before delivery.

    4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here willing to be your technical consultant.

    5. Quick Delivery: Our company provides just-in-time delivery.

    6. Prompt Response to Customers: Your satisfaction is the goal we pursue.

    APPLICATION

    This machine is widely applicable to seam welding of all kinds of mental pipe.


    DESCRIPTION


    1. Automatic straight seam welding machine adopts argon arc welding machine as the welding power source. The stepping motor drives the welding gun to conduct constant speed movement. The moving speed and length is set through PLC; use pneumatic pressing plate to press to ensure the stability and consistency of welding; the action program of the whole machine is controlled by PLC; use the touch screen to input data.

    2. Maximum work piece length: 300/500/1000/1500/2000mm

    3. Welding thickness: 0.3-8.0mm

    4. Welding speed: 30-800mm/min


    SPECIFICATION


    No.

    Item

    Data

    1

    Input Voltage

    380V three-phase

    2

    Input current

    15Ax3

    3

    Min welding thickness

    0.2mm

    4

    Max welding thickness

    3mm

    5

    Work piece max welding length

    1500mm

    6

    Work piece max diameter

    1000mm

    7

    Work piece min diameter

    300mm

    9

    Welding gun moving speed

    0.5m/sec
